Project

General Electrical Specification

Absolute Maximum Ratings:

Ratings  Min.  Max.
Storage Temperature  -40 +85
Supply Voltage (VCHG)  -0.4V  5.75V
Supply Voltage (VREG_ENABLE,VBAT_SENSE)  -0.4V  4.2V
Supply Voltage (LED[2:0])  -0.4V  4.4V
Supply Voltage (PIO_POWER)  -0.4V  3.6V

Recommended Operating Condition:

Operating Temperature range  -20 +75
Supply Voltage (VBAT)  2.7V  4.25V
Supply Voltage (VCHG)  4.75V / 3.10 V  5.25V
Supply Voltage (VREG_ENABLE,VBAT_SENSE)  0V  4.2V
Supply Voltage (LED[2:0])  1.10V  4.25V
Supply Voltage (PIO_POWER)*  1.7V  3.6V

1.8V Switch-mode Regulator :
